For over 60 years, we've controlled every link in the chain - from raw oil refining to PVC film manufacturing and final inflatable product assembly. All factories are self-built on company-owned land. The full ownership supports continuous capacity expansion, no compromises of quality controlling , and underscores our dedication to long-term business partnerships.

•

  1996

  Heshan District

  Crude oil-VCM Production-PVC resin

•

  1998

  Nansha District

  PVC pool liner factory

  PVC Membrane factory

  PVC drop stitch factory

  All raw materials are from our own controlled chemical factory

•

  2013

  Jiangmen District

  PVC Inflatables factory

  All air-tight PVC, Pool liner and drop stitch materials are from self-owned factories.

•

  2019

  Malaysia

  Vinyl pool liner factory

  water inflatables factory

  To help customers to avoid possible customs risk, we have also factories in Malaysia.



Our laboratory is equipped with industry-grade instruments including XRF, GC-MS, and UV aging chambers, enabling full compliance testing to international standards for PVC pool liner such as RoHS and REACH.

tensile test

Read More

water pressure test

Read More

low temperature testing

Read More

New product development machine

Read More

Main procedures of pool vinyl liner

High-speed mixer: Raw materials - PVC resin, plasticizers, heat stabilizers, fillers, and pigments - are precisely weighed and then blended in a high-speed mixer. Friction heat (~110–120°C) turns the mix into a dry, free-flowing powder, which is then cooled in a separate cooling mixer to stop it from gelling too early.

High-speed mixer

Raw materials - PVC resin, plasticizers, heat stabilizers, fillers, and pigments - are precisely weighed and then blended in a high-speed mixer. Friction heat (~110–120°C) turns the mix into a dry, free-flowing powder, which is then cooled in a separate cooling mixer to stop it from gelling too early.

Internal (Banbury) mixer

The dry blend is fed into an internal mixer, where intense shear and heat (~160–180°C) melt it into a soft, homogeneous mass. A two-roll mill then works it further and feeds a continuous strip toward the calender - usually after a screen pack and metal detector strain out any contaminants.

Four-roll calender

The core step This is the heart of the line. The molten compound passes through four heated, rotating rolls - arranged in an L, inverted-L, Z, or S layout - with progressively narrower gaps. Each gap squeezes the material thinner, forming it into a film of precise, uniform thickness with a smooth surface.

Embossing, cooling & winding

After the calender, an embossing roll can press a texture or pattern into the surface (for matte or leather-look films). Cooling drums then set the film, an online thickness gauge checks quality, and finally the winder rolls the finished film into large master rolls - ready for slitting or further processing.
